Sony SRG-300SEW HD Colour Video Surveillance Camera

QuickFind: 670497 Mfr part code: SRG-300SEW
  • 1/2.8" Exmor CMOS Sensor
  • Remote Pan, Tilt, and Zoom
  • 30x Optical Zoom
  • 1.4 lux (50IRE, f/1.6, 30 fps)
  • View-DR & XDNR Technology

Product Description

Sony SRG-300SEW HD Colour Video Surveillance Camera

Sony SRG-300SEW 1080p Desktop & Ceiling Mount Remote PTZ Camera - White

White Remote Desktop & Ceiling Mount 1080p PTZ Camera from Sony

With a 30x optical zoom and remote control capabilities, the White Sony SRG300SE 1080p Desktop & Ceiling Mount Remote PTZ Camera, is suitable for medium to large venues such as lecture halls, auditoriums, houses of worship, and stadiums. The unit consists of the pan/tilt module and the camera head and lens. The SRG300SE captures HD video in 720p, 1080i, or 1080p at up to 59.94. It features a 1/2.8" Exmor CMOS sensor providing low light sensitivity of 1.4 lux. The camera comes with Sony's Wide-D for wide dynamic range, enhancing the image with View-DR, while XDNR provides digital noise reduction in both moving and still images.

The SRG300SE is suitable for use on a desk, mounted to a tripod, or you can mount it to a ceiling using the included brackets. The camera also features an Image Flip option, which simplifies setting up the camera when it is mounted upside down. It features remote control operation of pan, tilt, zoom, focus, iris, shutter speed, and gain.
Remote operation is a major component of the SRG300SE's design, and the camera supports VISCA control protocols, as well as RS-232 and RS-422. You can program the camera with up to 16 preset positions, which is useful for repetitive events and productions. The small size and remote operation capabilities of the SRG300SE allow for placement where a manually operated camera and operator can not go.

SRG-300SE Features

  • The SRG-300SE provides simultaneous 3G-SDI and IP H.264 streaming. This allows you to feed an SDI infrastructure a 3G-SDI signal, while streaming web ready video stream without using an external encoder to convert your video signal to a web friendly format.
  • Web-viewing function allows remote camera control for up to 20 clients. Up to 10 clients can receive video and audio combined streaming.

Remote Operation
Remote operated HD camera with pan, tilt, zoom, focus, iris, and shutter speed control

Zoom Range
The SRG300SE provides up to 30x optical zoom, and 12x digital zoom

Camera Control
VISCA over IP technology allows for control of the camera over an IP connection.

RS-232 and RS-422 control of the camera
The camera supports programming of up to 16 preset positions using optional controllers such as the Sony RMIP10

Wide-D/View-DR
View-DR is Sony's Wide-D technology, specific to their security cameras to produce images with an extremely wide dynamic range. With View-DR, the camera uses an electronic shutter to capture multiple images, to reproduce each frame. One image is taken using a 'standard' exposure time and either one or three images are taken using very short exposure times depending on the camera type. As a result, View-DR nearly doubles the sensitivity compared to conventional Wide-D technologies.

XDNR Noise Reduction
XDNR utilizes 2D and 3D noise reduction methods adaptively to scenes. Under low-light conditions, XDNR provides clear images for both moving objects and still portions of the image.

Key Features:

  • 1/2.8" Exmor CMOS Sensor
  • Remote Pan, Tilt, and Zoom
  • 30x Optical Zoom
  • 1.4 lux (50IRE, f/1.6, 30 fps)
  • View-DR & XDNR Technology
  • Simultaneous 3G-SDI & IP H.264 Output
  • Camera and Image Adjustment Menus
  • Up to 16 Preset Positions
  • Ceiling, Desktop, or Tripod Mount
  • Ethernet Control/RS-422



Technical Specification

Sony SRG-300SEW HD Colour Video Surveillance Camera

General

Audio Support Yes: two-way audio capability
Device Type Network surveillance camera
Camera Mount Type Ceiling mount
Connectivity Technology Wired
Width 15.7 cm
Depth 16.3 cm
Height 16.4 cm
Weight 1.4 kg

Camera

Digital Video Capture Resolution 1280 x 720, 720 x 480, 640 x 480, 352 x 288, 720 x 576, 704 x 576, 1920 x 1080, 640 x 360, 1024 x 576
Frame Rate 60 frames per second
Type Colour - Day&Night - pan / tilt / zoom
Digital Video Format H.264
Max Digital Video Resolution 1920 x 1080
Video Modes 1080/60i, 720/60p, 1080/50i, 720/50p, 1080/50p, 1080/60p, 1080/30p, 1080/25p, 720/30p, 720/25p
Digital Zoom 12
Exposure Range 1/1 sec - 1/10000 sec
Minimum Illumination 0.35 lux - colour - F1.6 - 50 IRE - shutter 1/30 sec / high-sensitivity mode on ¦ 1.4 lux - colour - F1.6 - 50 IRE - shutter 1/30 sec / high-sensitivity mode off
Video Capture 1920 x 1080 @ 60 fps ¦ 1920 x 1080 @ 30 fps
Supported Image Formats JPEG
Still Image Capture Resolution 1280 x 720, 720 x 480, 640 x 480, 352 x 288, 720 x 576, 704 x 576, 1920 x 1080, 640 x 360, 1024 x 576
Features Manual white balance, image stabilizer, image flip, Visibility enhanced wide Dynamic Range (View-DR), Visibility Enhancer, 256 preset positions, multi-streaming, manual gain control, Smartphone Monitoring, Variable Bitrate (VBR), Constant Bitrate (CBR), auto gain control, auto white balance, noise reduction

Titling

Range (degree) -20 to +90
Speed (degree/sec) Up to 90

Image Sensor

Type 2.1 MP Exmor CMOS 1/2.8"

Lens Construction

Type Motorized zoom
Optical Zoom 30 x
Focal Length 4.3 mm - 129 mm
Lens Iris F/1.6-4.7
Focus Adjustment Automatic, manual
Min Focus Distance 10 mm
Horizontal Field of View (degree) 63.7

Panning

Range (degree) -170 to +170
Speed (degree/sec) Up to 100

Tilting

Range (degree) -20 to +90
Speed (degree/sec) Up to 90

Interfaces

Video 3G-SDI
Network Interface Ethernet 10Base-T/100Base-TX
Network Protocols DHCP, DNS, HTTP, NTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, RTSP, RTP, HTTPS, IPv4, IPv6, RTCP, IGMP, SSL, QOS, DSCP
Control Interface RS-422

Expansion / Connectivity

Ports HD-SDI - BNC ¦ LAN - RJ-45 ¦ Serial RS-232 ¦ Audio line-in/microphone - RCA ¦ Audio line-in/microphone - 3.5 mm mono jack

Miscellaneous

Included Accessories 2 ceiling mount brackets
Colour White

Power

Power Requirements DC 10.8 - 13.2 V
Power Device 16.8 Watt

Software / System Requirements

OS Required Apple MacOS, Microsoft Windows 7 Professional (32/64 bits), Microsoft Windows 7 Ultimate (32/64 bits), Microsoft Windows Vista Business 32-bit Edition, Windows 8 Pro (32/64 bits), Microsoft Windows Vista Ultimate 32-bit Edition
System Requirements Details Core i7 - 2.8 GHz - RAM 2 GB

Environmental Parameters

Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
